AMERICAN STANDARD GAS OUTLET
Showing all 44 results
Compliant with NFPA99 and CGA standard
Gas Type: O2, MEDICAL AIR, VAC, N2O, N2, CO2 are available Combination structure
NFPA full color standard for easy gas identification
100% pressure and leakage tested
360°swivel on the inlet pipe for easy installation
Available in wall type with box, console type on bedhead units and hose barb type
Suitable ambient temperature: -20℃ to 60℃, ambient humidity: 10% to 95%
The working pressure for oxygen, air (breathing), nitrous oxide, and carbon dioxide is 0.4MPa
The working pressure for nitrogen and instrument air is 0.8MPa
The negative pressure working pressure is -0.075MPa The maximum gas supply flow rate is more than 100L/min
the maximum suction flow rate is more than 40L/min
