LCD MEDICAL GAS MANIFOLD SYSTEM
Showing all 1 results
Input Pressure 0.8~15Mpa
Output pressure 0.4~1.0Mpa (adjustable).
Changeover flow >80m³/h
Tube interface ribbed M33×2 (can be made on request).
Switching pressure 0.6~1Mpa (configurable).
Operating voltage AC24V
Operating current 250mA
The opening pressure of the safety valve 2.0Mpa
Use the residual air pressure of the cylinder ＜0.8MPa
Overall dimensions 600×500×200mm
