JAPANESE STANDARD GAS OUTLET
Showing all 1 results
100% pressure and leakage tested
Gas Type: O2, MEDICAL AIR, VAC, N2O, N2, CO2 are available
Compliant with JIS and CGA standard
Color-coded according to JIS color Standard
Available in wall type with box, console type on bedhead units and hose barb type
Secondary isolating valve enables easy maintenance, without shutting down the pipeline system
Suitable ambient temperature: -20℃ to 60℃, ambient humidity: 10% to 95%
The working pressure for oxygen, air (breathing), nitrous oxide, and carbon dioxide is 0.4MPa
The working pressure for nitrogen and instrument air is 0.8MPa
The negative working pressure is -0.075MPa
The maximum gas supply flow rate is more than 100L/min; the maximum suction flow rate is more than 40L/min
