Flow-Type Negative Pressure Regulator

SRS-8

The flow adjustment valve can withstand a working pressure of 0.8MPa without any leakage.

The medical air pressure is greater than or equal to 0.35MPa (the recommended pressure range is  0.35MPa to 0.5MPa), and by adjusting the gas flow rate, the maximum negative pressure value can  reach above -0.07MPa.

By adjusting the medical air flow rate adjustment valve, the positive pressure gas flow rate can be  adjusted, and the negative pressure value can be arbitrarily adjusted within the range of 0 to  -0.07MPa.

Connect the negative pressure hose to the negative pressure connector and quickly insert the  corresponding positive pressure quick plug into the positive pressure power source socket for use.

Within the recommended pressure range, counterclockwise rotation of the flow adjustment valve  increases the negative pressure value, and clockwise rotation decreases the negative pressure  value.
